Help for ocpp.csms.view_energy_graph

def view_energy_graph(*, charger_id=None, date=None, **_):
    """
    Render a page with a graph for a charger's session by date.
    """
    import glob
    from datetime import datetime
    html = ['<link rel="stylesheet" href="/static/styles/charger_status.css">']
    html.append('<h1>Charger Transaction Graph</h1>')

    # Form for charger/date selector
    graph_dir = gw.resource("work", "etron", "graphs")
    charger_dirs = sorted(os.listdir(graph_dir)) if os.path.isdir(graph_dir) else []
    txn_files = []
    if charger_id:
        cdir = os.path.join(graph_dir, charger_id)
        if os.path.isdir(cdir):
            txn_files = sorted(glob.glob(os.path.join(cdir, "*.json")))
    html.append('<form method="get" action="/ocpp/csms/energy-graph" style="margin-bottom:2em;">')
    html.append('<label>Charger: <select name="charger_id">')
    html.append('<option value="">(choose)</option>')
    for cid in charger_dirs:
        sel = ' selected' if cid == charger_id else ''
        html.append(f'<option value="{cid}"{sel}>{cid}</option>')
    html.append('</select></label> ')
    if txn_files:
        html.append('<label>Transaction Date: <select name="date">')
        html.append('<option value="">(choose)</option>')
        for fn in txn_files:
            # Filename: YYYY-MM-DD_<txn_id>.json
            dt = os.path.basename(fn).split("_")[0]
            sel = ' selected' if dt == date else ''
            html.append(f'<option value="{dt}"{sel}>{dt}</option>')
        html.append('</select></label> ')
    html.append('<button type="submit">Show</button></form>')

    # Load and render the graph if possible
    graph_data = []
    if charger_id and date:
        base = os.path.join(graph_dir, charger_id)
        match = glob.glob(os.path.join(base, f"{date}_*.json"))
        if match:
            with open(match[0]) as f:
                graph_data = json.load(f)
        # Graph placeholder: (replace with your JS plotting lib)
        html.append('<div style="background:#222;border-radius:1em;padding:1.5em;min-height:320px;">')
        if graph_data:
            html.append('<h3>Session kWh Over Time</h3>')
            html.append('<pre style="color:#fff;font-size:1.02em;">')
            # Show simple table (replace with a chart)
            html.append("Time                | kWh\n---------------------|------\n")
            for mv in graph_data:
                ts = mv.get("timestampStr", "-")
                kwh = "-"
                for sv in mv.get("sampledValue", []):
                    if sv.get("measurand") == "Energy.Active.Import.Register":
                        kwh = sv.get("value")
                html.append(f"{ts:21} | {kwh}\n")
            html.append('</pre>')
        else:
            html.append("<em>No data available for this session.</em>")
        html.append('</div>')

    return "".join(html)
