OCPP Components

projects/ocpp contains a minimal OCPP 1.6 demo implementation. The submodules are:

  • csms – a simple Central System with a status dashboard.
  • evcs – a charge point simulator that connects to csms.
  • sink – a message logger for debugging.
  • rfid – helpers for RFID allow/deny checks.

Launch a simulator session pointing at your CSMS with:

gway ocpp.evcs simulate \
    --host 127.0.0.1 --ws-port 9000 \
    --cp-path ocpp/csms/CPX

The simulator can also be controlled via the web UI at /ocpp/evcs/cp-simulator (call gw.ocpp.evcs.view_simulator).

The simulator accepts --kwh-min and --kwh-max to control the approximate energy delivered per session. For example, --kwh-min 40 --kwh-max 70 will produce sessions around 40–70 kWh. Use --interval to specify how often MeterValues are sent (default 5s). The --pre-charge-delay option keeps the charger idle for the given number of seconds after connecting while it sends Heartbeats and idle MeterValues.

Open /ocpp/csms/active-chargers in your browser to view all connected chargers. Each card refreshes every few seconds so data stays current. Click a charger to open its detail page where you can send commands like Stop or Soft Reset and watch the log update in real time. The auto-refresh will collapse any open panels; you can temporarily disable it by removing the gw-refresh attribute from the page.

The charger detail view also lists recent transactions. By default it shows the last 24 hours but you can adjust the period with the date selectors above the table.

Etron Recipes

recipes/etron contains GWAY recipes used in real EV charging demos:

  • local.gwr – start both the CSMS dashboard and a simulator on the same machine for quick testing.
  • cloud.gwr – run a CSMS instance for cloud deployments. Use ocpp.rfid.approve with a CDV table to control RFID access.
  • local_proxy.gwr – run a local CSMS that forwards unknown requests to a remote instance. This keeps sessions operational when offline and syncs with the cloud once connectivity returns.

Run them via gway run <recipe>. For example:

gway run recipes/etron/local.gwr

The integration suite includes tests/test_proxy_fallback.py which starts both the local and cloud recipes to verify that requests are proxied once the cloud is available. Enable it with the proxy test flag. This harness can serve as a template for offline-first deployments.

OCPP Data Storage

ocpp.data provides helper functions to persist transactions, meter values and error reports in work/ocpp.sqlite using gw.sql. The csms module calls these helpers so charging sessions are recorded automatically.

For comparison with real EVCS logs, every completed transaction is also written as a .dat file under work/ocpp/records/<charger_id>/.

Both the server time and the charger-provided timestamp are stored for each transaction event. This lets you verify the charger's clock during reconciliation.

To review stored information you can render a simple summary table with:

gway ocpp.data.view_charger_summary

This shows the number of sessions and total energy per charger along with the timestamp of the last stop and any last recorded error.

Two additional views provide more insight into stored data:

view_charger_details displays transaction records for one charger with simple filtering and pagination. view_time_series returns a chart of energy usage over time for selected chargers and dates.
