Help Topics for awg

awg · find_cable

Sample CLI

gway awg find-cable

References

debug, info, sql, sql.open_connection

Signature

(*, meters: Union[int, str, NoneType] = None, amps: Union[int, str] = '40', volts: Union[int, str] =
'220', material: Literal['cu', 'al', '?'] = 'cu', max_lines: Union[int, str] = '1', phases:
Literal['1', '3', 1, 3] = '2', conduit: Union[str, bool, NoneType] = None, ground: Union[int, str] =
'1')

Docstring

Calculate the type of cable needed for an electrical system. Args: meters: Cable length (one line) in meters. Required keyword. amps: Load in Amperes. Default: 40 A. volts: System voltage. Default: 220 V. material: 'cu' (copper) or 'al' (aluminum). Default: cu. max_lines: Maximum number of line conductors allowed. Default: 1 phases: Number of phases for AC (1, 2 or 3). Default: 2 conduit: Conduit type or None. ground: Number of ground wires. Returns: dict with cable selection and voltage drop info, or {'awg': 'n/a'} if not possible.
awg · find_conduit

Sample CLI

gway awg find-conduit

References

sql, sql.open_connection

Signature

(awg, cables, *, conduit='emt')

Docstring

Calculate the kind of conduit required for a set of cables.
awg · view_cable_finder

Sample CLI

gway awg view-cable-finder

Signature

(*, meters=None, amps='40', volts='220', material='cu', max_lines='3', phases='1', conduit=None,
neutral='0', **kwargs)

Docstring

Page builder for AWG cable finder with HTML form and result.

TODOs

# TODO: Add a image with the sponsor logo on the right side of the result page
